SPECIFICATIONS:
Input Frequency:3.4-4.2 GHz
Output Frequency:950-1750MHz
Focal Length(cm):57.0
L.O Frequency:5.15GHz¡À1MHz
L.O.Phase Noise:
-50dBc/Hz@1KHz(OFFSET)
-75dBc/Hz@10KHz(OFFSET)
-95dBc/Hz@100KHz(OFFSET)
Polarity:SWITCHED H and V
Conversion Gain:65dB(typ)
Noise Figure:15K(min)
Gain Flatness:¡À0.75dB/36 MHz
Image Rejection:45dB(min)
Output V.S.W.R:2.5:1
Twin Switching:0/22K SW
DC Supply Voltage:0-14.5V(V),15.5-25V(H)
Supply Current:150 mA(MAX)
Rf Input Connecter:WAVE GUIDE WC-229
If Output Connecter:F TYPE FEMALE 75&Omega
|
